VIBRATING SCREEN
Svs Series
VIBRATING SCREEN
SONIKH inclined screens are versatile. They can be used for primary, secondary and tertiary screening. The standard slope angle of the screen is 17, although it can be adjusted for specific applications. SVS SERIES inclined screens offer reliable and versatile screening in aggregates production plants, quarries, gravel pits and mining
operations. Their circular motion and variable slope help you achieve a high production capacity and improve profitability.
SPECIFICATION
| MODEL | SVS- 1548 | SVS-1848 | SVS- 1554 | SVS- 1560 | SVS- 1860 | SVS- 2160 |
|---|---|---|---|---|---|---|
(SIZE) |
3 / 4-DECK
16’X5’ |
3 / 4-DECK
16’X6’ |
3 / 4-DECK
18’X5’ |
4-DECK
20’X5’ |
4-DECK
20’X6’ |
4-DECK
20’X7’ |
L=MAX
LENGTH |
4800 |
4800 |
5800 |
6000 |
6000 |
6000 |
W=MAX
WIDTH |
1540 |
1800 |
1540 |
1540 |
1860 |
2160 |
H=MAX
HEIGHT |
3000 |
3000 |
3770 |
3500 |
4000 |
4000 |
MOTOR
POWER |
15HP |
20 HP |
20 HP |
30 HP |
30 HP |
40 HP |
