DOUBLE ROLLER
SDR Series
DOUBLE ROLLER
Sonikh Double roller crusher is mainly used for secondary and fine crushing materials with soft or middle hardness like coal, coke, limestone, clinker mineral, slag. Depending on the requirements, the rollers are smooth or toothed.
SPECIFICATION
MODEL TYPE |
SIZE |
SDR 5060 S |
SDR 6060 S |
SDR 8060 S |
SDR 8080 S |
SDR 8010 S |
SDR 1080 S |
SDR 1010 S |
SDR 1012 S |
SDR 1212 S |
SDR 1415 S |
|---|---|---|---|---|---|---|---|---|---|---|---|
Application
| Coal, Limestone, dolomite, slag, Refractory
| ||||||||||
Roller Dia
|
mm
|
500
|
600
|
800
|
800
|
800
|
1000
|
1000
|
1000
|
1200
|
1400
|
Roller Width
|
mm
|
600
|
600
|
600
|
800
|
1000
|
800
|
1000
|
1200
|
1200
|
1500
|
Max. feed Size
|
mm
|
20
|
20
|
30
|
30
|
30
|
40
|
40
|
50
|
60
|
80
|
Product Size
|
mm
|
0 - 6
|
0 - 8
|
0 - 8
|
0 - 8
|
0 - 10
|
0 - 10
|
0 - 10
|
0 - 12
|
0 - 15
|
0 - 20
|
Capacity
|
MTPH
|
6.-20
|
15-35
|
25-50
|
30-60
|
35-50
|
40-80
|
40-80
|
40-80
|
40-80
|
40-80
|
Motor Power
|
HP
|
10
|
30
|
30
|
40
|
60
|
60
|
75
|
100
|
120
|
150
|
Motor Install
|
No
|
2
|
2
|
2
|
2
|
2
|
2
|
2
|
2
|
2
|
2
|
