JAW CRUSHER HC
HC SERIES
JAW CRUSHER
SONIKH JAW CRUSHERS Are Commonly Classified by The Degree to Which They Fragment the Starting Material. With Primary & Secondary Crusher Handling Course material & crush reducing particle as per finer graduation.
Various type of crusher and mineral separator may be employed depends up on the Throughput, hardness & Properties of the mineral being processed. In all the cases Crushing stages are essential achieved by transferring a mechanically amplified force through Mechanical advantage to a material.
TECHNICAL DATA
SPECIFICATION
| MODEL | UNIT | HC56 | HC68 | HC96 | HC108 | HC118 | HC130 | HC135 | HC140 |
|---|---|---|---|---|---|---|---|---|---|
H Max, Max height from jaw |
(MM) |
1685 |
1900 |
2610 |
2810 |
2900 |
3110 |
3300 |
3900 |
TF Overall feed height |
(MM) |
1030 |
1600 |
1910 |
2050 |
2150 |
2360 |
2420 |
2670 |
L. Max Length |
(MM) |
2175 |
2350 |
2750 |
3000 |
3060 |
3150 |
3300 |
3540 |
W, Max
Width |
(MM) |
2010 |
2150 |
2185 |
2510 |
2580 |
2650 |
2650 |
2810 |
D. Flywheel
diameter |
(MM) |
1100 |
1200 |
1400 |
1500 |
1500 |
1600 |
1800 |
1800 |
Crushers
speed |
RPM |
290 |
290 |
270 |
260 |
260 |
220 |
220 |
220 |
Motor
Power |
HP |
60 |
75 |
120 |
150 |
150 |
200 |
215 |
240 |
KW |
45 |
55 |
90 |
111 |
111 |
150 |
160 |
178 | |
Total Weight |
TON |
11.6 |
17.2 |
19.5 |
24 |
26.8 |
33 |
34.5 |
42.5 |
| OPERATING LIMITS | |||||||||
|---|---|---|---|---|---|---|---|---|---|
Feed Opening |
MM |
762X 508 |
812X 609 |
914X 711 |
1066X762 |
1117X 812 |
1219X 914 |
1219X 1066 |
1371 X 1219 |
INCH |
30×20 |
32×24 |
36×28 |
42×30 |
44×32 |
48×36 |
48×42 |
54×48 | |
CSS Min-Max |
MM |
62-180 |
75-200 |
100-220 |
100-250 |
125-250 |
125-250 |
125-300 |
150-300 |
